Seamless Pipe Manufacturer in India
We are leading Manufacturers, Supplier, Dealers, and Exporter of Seamless Pipes in India. Our Seamless Pipes are available in different sizes, shapes, and grades. We supply these Pipes in most of the major Indian cities in more than 20 States. We Sachiya Steel International offer different types of grades like Stainless Steel Pipes, Super Duplex Steel Pipes, Duplex Steel Pipes, Carbon Steel pipes, Alloys Steel pipes, Nickel Alloys pipes, Titanium Steel pipes, Inconel Steel pipes, Aluminium pipes, etc.
Seamless Pipes | Specifications | |||
---|---|---|---|---|
Schedule | SCH5, SCH10, SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120,SCH140, SCH160, XXS | |||
Standard | ASME/ANSI B16.11, MSS-SP-97, MSS-SP-79, JIS B2316, BS 3799 | |||
Pipes Size | 1/8″NB to 24″NB & 1/4″OD TO 24″OD AND 6.35mm to 254mm OD Thickness: 0.6mm to 20mm | |||
Type | Seamless/ erw/ welded/semi welded in round, square, rectangular, coil form, u shape and hydraulic. Pipes | |||
Grades | ||||
Stainless Steel | ASTM / ASME 201, 202, 301, 304, 304L, 310, 310S, 316L, 316TI, 317, 317L, 321, 347, 409, 409M, 409L, 410, 410S, 420, 430, 431, 441, 444, 446, 17.4PH, 904L | |||
Super Duplex Steel | S32750 | |||
Duplex Steel | ASTM / ASME SA 790 UNS NO S 31803 , S 32205 , S 32550 , S 32750 , S 32760. | |||
Carbon Steel | ASTM / ASME A 335 GRP 1 , P 5 , P 9 , P 11 , P 12 , P 22 , P 23 , P 91 | |||
Alloys Steel | ASTM / ASME A 691 GRP1 CR , 1 1/4 CR , 2 1/4 CR , 5 CR , 9CR , 91. | |||
Nickel Alloys | Nickel Alloys 200, Nickel Alloys 201 | |||
Titanium | Grade 1, Grade 4, Grade 5(Ti 6Al-4V), Grade 6(Ti 5Al-2.5Sn), Grade 7, Grade 11, Grade 12, 8Ai-1Mo-1V, Grade 9(3Al-2.5V), 6Al-6V-25n, 6Al-2Sn-4Zr-2Mo, 6Al-7Nb, Grade 23(Ti 6AL-4V ELI), Grade 5 ELI | |||
Inconel | Inconel 600, Inconel 601, Inconel 625, Inconel 625LCF, Inconel 686, Inconel 718, Inconel 800, Inconel 825, Inconel X-750 , Inconel 690, Inconel 602, Inconel 617, Inconel 925, Inconel A-289, Inconel AL-6XN, AL-904L | |||
Hastelloy | Hastelloy C-22, Hastelloy C-276, Hastelloy C-2000, Hastelloy C-4, Hastelloy X, Hastelloy B, Hastelloy N, Hastelloy G | |||
Molybdenum | ASTM / ASME A 182 GR F 5, F 9 , F 11 , F 12 , F 22 , F 91, ASTM B387, Ferro Molybdenum | |||
Cobalt | Cobalt HS-6, Cobalt HS-4, Cobalt HS-25, Sterlite Grade 1, Sterlite Grade 6, Sterlite Grade 12, Sterlite Grade 21 | |||
Niobium | ASTM B394, R04200 R04210 | |||
Nimonic | Nimonic75, Nimonic80, Nimonic85, Nimonic90, Nimonic263, etc | |||
Tungsten | W1 WAl1, W61, etc, Carbonide Tungsten, Copper Tungsten, Nickel Tungsten | |||
Nichrome | Nichrome90, Nichrome80, Nichrome80A, Nichrome RW80, Nichrome75, etc | |||
Magnesium | Magnesium AL017100, AL017140, AL017150, AL017160, AL017200, AL017210, AL017250, etc. | |||
Tantalum | Tantalum – Grade 1. | |||
Monel | Monel 400, Monel k500 | |||
MU-METAL | MU-METAL | |||
Zirconium | Zirconium 702, Zirconium 705,Zirconium 705, Zirconium-2, Zirconium-4 | |||
Beryllium Copper | Alloy 25 UNSC17200 | |||
Aluminium | 1050,1100, 2017, 7150, 7178, 7575, 2050, 7085, 2011 A92011, 2014A A92014, 2024 A92024, 2219, 5052 A95052, 5083 A95083, 5754, 6061 A96061 A86061, 6063, 6082 A96082, 7071 7020, 7050 A97050, 7075 A97075 A87075, 7175 | |||
Copper Alloys | C 11000, C 10200, C 12200, C 51100, C 51000, C 51900, C 52000, C 52100, C 74500, C 75700, C 75400, C 76400, C 77000, C 21000, C 22000, C 23000, C 24000, C 26000, C 26800, C 27000, C 27200, C 28000 |
Seamless Pipe Manufacturer in India
We are leading Manufacturers, Supplier, Dealers, and Exporter of Seamless Pipes in India. Our Seamless Pipes are available in different sizes, shapes, and grades. We supply these Pipes in most of the major Indian cities in more than 20 States.
Pipes according to ASTM A312 | ||||||||
Grade | C | Mn | P | S | Si | Cr | Ni | Mo |
TP 304 | 0.08 | 2.0 | 0.045 | 0.030 | 1.0 | 18.0-20.0 | 8.0-11.0 | |
TP 304L | 0.035 | 2.0 | 0.045 | 0.030 | 1.0 | 18.0-20.0 | 8.0-13.0 | |
TP 316L | 0.035 | 2.0 | 0.045 | 0.030 | 1.0 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
Note: For small diameter or thin walls or both, where many drawing passes are required, a Carbon maximum of 0.040% is necessary in grades TP 304L and TP 316L. Small outside diameter tubes are defined as those less than 0.50 in. [12.7 mm] in outside diameter and light wall tubes as those less than 0.049 in. [1.20 mm] in average wall thickness (0.044 in. [1.10 mm] in minimum wall thickness). |
Seamless Pipe may be furnished bare or coated and with capped ends. pipes up to 3” OD will be supplied in bundles. In order to prevent rust during sea shipment, bundles of Seamless Pipe may be wrapped with polypropylene sheets, and secured with flat steel bands. Over 3” OD will be supplied loose.
- Off-Shore Oil Drilling Companies
- Power Generation
- Petrochemicals
- Gas Processing
- Specialty Chemicals
- Pharmaceuticals
- Pharmaceutical Equipment
- Chemical Equipment
- Sea Water Equipment
- Heat Exchangers
- Condensers
- Pulp and Paper Industry
We at Sachiya Steel International provide Manufacturer TC (Test Certificate) in accordance to EN 10204/3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report. We also provide Standard certificates like EN 10204 3.1 and additional requirement like. NACE MR 01075. FERRIT CONTENT as per norms if requested by clients.
- EN 10204/3.1B
- Raw Materials Certificate
- 100% Radiography Test Report
- Third Party Inspection Report, etc
We at Sachiya Steel International ensure that all our materials go through strict quality tests before dispatching them to our clients.
- Mechanical Testing Such as Tensile of Area
- Hardness Test
- Chemical Analysis – Spectro Analysis
- Positive Material Identification – PMI Testing
- Flattening Test
- Micro and Macro Test
- Pitting Resistance Test
- Flaring Test
- Intergranular Corrosion (IGC) Test
- Commercial Invoice which includes HS Code
- Packing List including net weight and gross weight, number of boxes, Marks and Numbers
- Certificate of Origin legalized/attested by Chamber of Commerce or Embassy
- Fumigation Certificates
- Raw Material Test Reports
- Material Traceability Records
- Quality Assurance Plan (QAP)
- Heat Treatment Charts
- Test Certificates certifying NACE MR0103, NACE MR0175
- Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2
- Guarantee Letter
- NABL approved Laboratory Test Reports
- Welding Procedure Specification/Procedure Qualification Record, WPS/PQR
- Form A for the purposes of the Generalized System of Preferences (GSP)
