Sachiya Steel International is one of the Leading Manufacturer And Exporter Of High Quality Stainless Steel 316Ti Nuts And Bolts, which exhibits excellent resistance in a variety of atmospheres and temperatures, along with the corrosion and oxidation that occurs over time. Stainless Steel 316Ti Hex Head Bolts is often applied in areas of higher temperatures than Type 304 can endure, and its low carbon allows it to be resistant against carbon precipitation. However, like many stainless steels, Stainless Steel 316Ti Hex Head Nuts is susceptible to warm chlorine environments and can potential pit and crack.
This utilized the widely applicable properties of Stainless Steel 316Ti Square Bolts and meets the individual specifications for each. Additionally, the lower amount of carbon in its composition gives Stainless Steel 316Ti Square Nuts utilization in areas where high temperature gases may pose a problem. As such, Stainless Steel 316Ti Eye Bolts is commonly applied in the manufacturing of furnaces, exhaust systems and containers exposed to high temperatures.
Stainless Steel 316Ti Eye Nuts is additionally characterized by its resistance to oxidation and creep, along with its ability to withstand high temperatures. Moist environments have no effect on Stainless Steel 316Ti U-Bolts, due to the higher levels of nickel and chromium in its makeup. Because of this, Stainless Steel 316Ti Wing Nuts is often utilized in marine environments in place of Stainless Steel 304, as it displays a higher resistance.
SS 316Ti Bolt/Nut Specifications |
||
Specifications | : | ASTM A 193 ASME SA 193 |
Standard | : | DIN, ASTM, BS and all International Standards |
Length | : | 3 mm to 200 mm |
Size | : | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
Type | : | Hex Head Bolts, Square Bolts, U bolts, Eye bolts, T bolt, Hex Bolt, Lag Bolts, Counter sunk Bolts, Hex Head nuts, Square nuts, Lock nuts, Eye nuts, wing nuts, T nuts, Panel Nuts, Coupling Nuts, Dome nuts, Acorn Nuts. |
316Ti Stainless Steel Bolt/Nut Chemical Composition
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
316Ti | min. | – | – | – | – | – | 16.0 | 2.00 | 10.0 | – |
max. | 0.08 | 2.0 | 0.75 | 0.045 | 0.030 | 18.0 | 3.00 | 14.0 | – |
Stainless Steel 316Ti Bolt/Nut Mechanical Properties
Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
Rockwell B (HR B) max | Brinell (HB) max | ||||
316Ti | 515 | 205 | 35 | 75 | 205 |
Stainless Steel 316Ti Bolt/Nut Physical Properties
Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Specific Heat 0-1000C (J/kg.K) | Electrical Resistivity (n.m) | |||
0-1000C | 0-3150C | 0-5380C | at 1000C | at 5000C | |||||
316Ti | 8000 | 193 | 17.2 | 17.8 | 18.4 | 16.2 | 21.5 | 500 | 720 |
Equivalent Grades for 316Ti Stainless Steel Bolt/Nut
Grade | UNS No | Old British | Euronorm | GOST | Japanese JIS | ||
BS | En | No | AFNOR | ||||
316Ti | S31635 | 320S31 | X6CrNiMoTi17-12-2 | 1.4571 | Z6CNDT17‐12 | 08Ch17N13M2T | SUS 316Ti |
SS 316Ti Bolt/Nut Application Industries
- Off-Shore Oil Drilling Companies
- Power Generation
- Petrochemicals
- Gas Processing
- Specialty Chemicals
- Pharmaceuticals
- Pharmaceutical Equipment
- Chemical Equipment
- Sea Water Equipment
- Heat Exchangers
- Condensers
- Pulp and Paper Industry
316Ti Steel Bolt/Nut Test Certificates
We at Sachiya Steel International provide Manufacturer TC (Test Certificate) in accordance to EN 10204/3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report. We also provide Standard certificates like EN 10204 3.1 and additional requirement like. NACE MR 01075. FERRIT CONTENT as per norms if requested by clients.
• EN 10204/3.1B,
• Raw Materials Certificate
• 100% Radiography Test Report
• Third Party Inspection Report, etc
Material Testing
We at Sachiya Steel International ensure that all our materials go through strict quality tests before dispatching them to our clients.
• Mechanical Testing Such as Tensile of Area
• Hardness Test
• Chemical Analysis – Spectro Analysis
• Positive Material Identification – PMI Testing
• Flattening Test
• Micro and Macro Test
• Pitting Resistance Test
• Flaring Test
• Intergranular Corrosion (IGC) Test
Documentation
• Commercial Invoice which includes HS Code
• Packing List including net weight and gross weight, number of boxes, Marks and Numbers
• Certificate of Origin legalized/attested by Chamber of Commerce or Embassy
• Fumigation Certificates
• Raw Material Test Reports
• Material Traceability Records
• Quality Assurance Plan (QAP)
• Heat Treatment Charts
• Test Certificates certifying NACE MR0103, NACE MR0175
• Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2
• Guarantee Letter
• NABL approved Laboratory Test Reports
• Welding Procedure Specification/Procedure Qualification Record, WPS/PQR
• Form A for the purposes of the Generalized System of Preferences (GSP)
Stainless Steel 316Ti Nuts
Sachiya Steel International is one of the Leading Manufacturer And Exporter Of High Quality Stainless Steel 316Ti Nuts And Bolts, which exhibits excellent resistance in a variety of atmospheres and temperatures, along with the corrosion and oxidation that occurs over time. Stainless Steel 316Ti Hex Head Bolts is often applied in areas of higher temperatures than Type 304 can endure, and its low carbon allows it to be resistant against carbon precipitation.
Product Brand: Sachiya Steel International
Product Currency: INR
Product Price: 120
Product In-Stock: InStock
