Sachiya Steel International is one of the efficient organizations in developing an exclusive range of Jindal ss pipe weight chart that can withstand high temperature and pressure. Sachiya Steel International is One Of the largest independent Stockholder of schedule 80 stainless steel pipe Weight, Stainless steel pipe Weight schedule 10 those are used in various industrial applications.

Check SS 304 Pipe weight per meter in India and Stainless Steel Square Pipe Weight Chart

The weight of steel is a very important aspect that helps in planning the entire project. To understand and accurately get the weight of the pipping grade, a Stainless Steel Pipe weight chart can be referred to. The weight of the pipe is calculated by multiplying the volume of the stainless steel material by the density of the material and is mentioned in the chart. The chart gives different pipe schedules that are given in combination with wall thickness and outer diameter of the pipe.

The Stainless Steel Square Pipe Weight Chart shows the sizes and material standards of square pipes. It specifies all the aspects of the pipe grade that help in estimating the strength and load-bearing capacity of the pipe across stress-induced setups. The pressure holding capacities are governed by the pressure class that helps in determining the pipe of specific weights that would be suitable for different projects. You can refer to the SS 304 Pipe weight per meter in India to understand the different aspects of the most common stainless steel grade. The information also plays a pivotal role in understanding the loads that can be transported of the select grade.

The Sch 40 Stainless Steel Pipe Weight Chart specifies the pipes in 1.68lbs per foot. These pipes have slightly thinner walls and are easy to transport and process. These pipes are suitable for use in moderate pressure setups. If you want to know in detail about the weights of different pipes of different configurations, you can download the pdf to get a complete outlook of the grade. For any queries or questions, contact us or visit any of our outlets for more information.

ss pipe weight chart
ss pipe weight chart



Sachiya Steel International offering Jindal stainless steel pipe weight chart India as per customer requirements. For pressure operations such as moving liquids and gases in processing operations in the water treatment, chemical, food processing, petrochemical, dairy, and marine industries check stainless steel pipe Weight Per Meter. Sachiya Steel International is specialized as providing Stainless steel Pipe Weight chart Metric in Polished Grit 120 – 600 finish. Stainless Steel Pipe Weight Calculator Online.

ss pipe weight chart, Stainless Steel Pipe Weight Table

Stainless Pipe Weight Per Meter, SS Pipe Weight Chart in Kg
Designation of Diameter O/D Nominal Wall Thickness
DIA SCH.5S SCH.5 SCH 10S SCH.10 SCH.20S SCH.30 SCH.40S SCH.40 SCH 60
(A) (B) Meter MM Wall Thk Weight Kg/Mtr Wall Thk Weight Kg/Mtr Wall Thk Weight Kg/Mtr Wall Thk Weight Kg/Mtr Wall Thk Weight Kg/Mtr Wall Thk Weight Kg/Mtr Wall Thk Weight Kg/Mtr Wall Thk Weight Kg/Mtr Wall Thk Weight Kg/Mtr
6 1/8 10.3 1 0.23 1.2 0.27 1.5 0.33 1.73 0.37
8 1/4 13.7 1.2 0.37 1.65 0.49 2 0.58 2.24 0.64
10 3/8 17.2 1.2 0.47 1.65 0.63 2 0.74 2.31 0.87
15 1/2 21.3 1.65 0.01 1.65 0.81 2.11 1.02 2.11 1.02 2.5 1.15 2.77 1.29
20 3/4 26.7 1.65 1.03 1.65 1.03 2.11 1.3 2.11 1.3 2.5 1.49 2.87 1.71
25 1 33.4 1.65 1.31 1.65 1.31 2.77 2.13 2.77 2.13 3 2.24 3.38 2.54
32 11/4 24.2 1.65 1.67 1.65 1.67 2.77 2.73 2.77 2.73 3 2.9 3.56 3.44
40 11/2 48.3 1.65 1.93 1.65 1.93 2.77 3.16 2.77 3.16 3 3.35 3.68 4.11
50 2 60.3 1.65 1.93 1.65 2.42 2.77 3.99 2.77 3.99 3.5 4.9 3.91 5.52
65 21/2 73 2.11 3.75 2.11 3.75 3.05 5.34 3.05 5.34 3.5 6 5.16 8.77
80 3 88.9 2.11 4.59 2.11 4.59 3.05 6.56 3.05 6.56 4 8.37 5.49 11.47
90 31/2 101.6 2.11 5.25 2.11 5.25 3.05 7.53 3.05 7.53 4 9.62 5.74 13.78
100 4 114.3 2.11 5.93 2.11 5.93 3.05 8.5 3.05 8.5 4.5 12.18 6.02 6.32
125 5 141.3 2.77 9.61 2.77 9.61 3.4 11.74 3.43 11.74 5 16.8 6.55 2210
150 6 168.3 2.77 11.47 2.77 11.47 3.4 14.04 3.43 14.04 5.5 22.08 7.11 28.69
200 8 219.1 2.77 15 2.77 15 3.76 20.77 3.76 20.27 6.35 33.82 7.04 37.38 8.18 43.2 10.81 53.9
250 10 273.1 3.4 22.95 3.4 22.95 4.19 28.2 4.19 28.2 6.35 42.41 7.8 51.81 9.27 61.22 12.2 82.8
300 12 323.9 3.96 31.72 4.19 33.6 4.57 36.54 4.57 36.54 6.35 50.48 8.38 66.2 9.53 75.01 10.31 80.94 14.27 110.62
350 14 355.6 3.96 34.86 4.78 41.99 6.35 55.53 7.92 68.95 9.53 82.58 9.53 82.58 11.13 96 15.06 128.42
400 16 406.4 4.19 42.2 4.78 48.07 6.35 63.61 7.92 79.03 9.53 94.7 9.53 94.7 12.7 125.2 16.66 162.59
450 18 457.2 4.19 47.46 4.78 54.15 6.35 71.69 7.92 89.1 11.13 124.32 9.53 106.83 14.27 158.27 19.05 209
500 2C 508 4.78 60.23 5.54 69.7 6.35 79.76 9.53 118.93 12.7 157.51 9.53 118.9 15.06 185.89 2062 251.65
550 22 558.8 4.78 65.95 5.54 76.75 6.35 87.84 9.53 131.07 12.7 173.66 9.53 131.07 15.88 216.04 22.23 298.55
600 24 609.6 5.54 83.8 6.35 95.92 6.35 95.92 9.53 143.2 14.27 212.72 9.53 143.2 17.45 258.74 24.59 360.21
650 26 660.4 7.92 129.4 12.7 205.97 9.53 155.32
700 28 711.2 7.92 139.47 12.7 222.13 15.88 276.48 9.53 167.44
750 3C 762 6.35 120.15 7.92 149.55 7.92 149.55 12.7 238.28 15.88 296.68 9.53 179.56
800 32 812.8 7.92 159.62 12.7 254.44 15.88 316.88 9.53 191.69 17.48 348.11
850 34 863.6 7.92 169.64 12.7 270.5 15.88 336.96 9.53 203.74 17.48 370.22
900 36 914.4 7.92 179.77 12.7 286.75 15.88 357.28 9.53 215.93 19.05 427.09

Stainless Steel Pipe Weight Chart Metric, Stainless Steel pipe standard weight chart, Weight Chart Of Stainless Steel Pipe, weight of stainless steel pipe grade 304, Unit weight of Stainless steel pipe 304

Designation of Diameter O/D Nominal Wall Thickness
DIA SCH 80 S SCH 80 SCH 100 SCH 120 SCH. 140 SCH.160 SCH.XXS
(A) (B) Meter MM Wall Thk Weight Kg/Mtr Wall Thk Weight Kg/Mtr Wall Thk Weight Kg/Mtr Wall Thk Weight Kg/Mtr Wall Thk Weight Kg/Mtr Wall Thk Weight Kg/Mtr Wall Thk Weight Kg/Mtr
6 1/8 10.3 2.41 0.47
8 1/4 13.7 3.02 0.82
10 3/8 17.2 3.2 1.12
15 1/2 21.3 3.73 1.64 4.75 1.97 7.47 2.59
20 3/4 26.7 3.91 2.93 5.54 2.93 7.82 3.69
25 1 33.4 4.55 3.29 6.35 4.3 9.09 5.53
32 11/4 24.2 4.85 4.53 6.35 5.69 9.7 7.88
40 11/2 48.3 5.08 5.49 7.14 7.35 10.16 9.69
50 2 60.3 5.54 7.6 8.71 11.26 11.07 13.65
65 21/2 73 7.01 11.59 9.53 15.15 14.02 20.72
80 3 88.9 7.62 15.51 11.13 21.67 15.24 28.11
90 31/2 101.6 8.08 18.92 16.15 34.56
100 4 114.3 8.56 22.66 11.13 28.75 13.49 34.05 17.12 41.66
125 5 141.3 9.53 31.44 12.7 40.9 15.88 49.87 19.05 58.31
150 6 168.3 10.97 43.21 14.27 55.03 18.24 68.53 21.95 79.1
200 8 219.1 12.7 65.63 15.06 76.93 18.24 91.73 20.62 102.47 23.01 112.97 22.23 108
250 10 273.1 12.7 82.8 15.06 97.27 18.24 116.38 21.41 134.9 25.4 157.51 28.58 174.95 25.4 155.5
300 12 323.9 12.7 98.95 17.45 133.88 21.41 162.14 25.4 189.82 28.58 211.31 33.32 242.4 25.4 189.82
350 14 355.6 12.7 109.04 19.05 160.54 23.8 197.74 27.76 227.88 31.75 257.47 35.71 286.04
400 16 406.4 12.7 125.2 21.41 206.4 26.19 249.34 30.94 290.88 36.53 338.32 40.46 370.74
450 18 457.2 12.7 141.35 23.8 258.29 29.36 314.54 34.93 369.34 39.67 414.74 45.24 466.67
500 2C 508 12.7 157.51 26.19 315.97 32.54 387.41 38.1 448.3 44.45 515.94 49.99 573.31
550 22 558.8 12.7 173.66 28.57 379.7 34.92 457.83 41.27 535.17 47.62 609.3 53.97 682.57
600 24 609.6 12.7 189.82 30.94 448.3 38.89 555.76 46.02 649.44 52.37 730.72 59.51 819.7
650 26 660.4 12.7 205.97 (24.66D-t) t 1000 Wt/pam + formula Weight Stainless Steel Pipe OD (mm) – W.T. (mm) XW.T. (mm) X 0.02466=Kg. per mtr.
700 28 711.2 12.7 222.13
750 3C 762 1270 238.28
800 32 812.8 12.7 254.44
850 34 863.6 12.7 270.5
900 36 914.4 12.7 286.75

Stainless Steel Pipe Weight Per Foot

ss pipe weight chart

Upper Value– Indicates wall thickness in inches.
Lower Value– Indicates weight per foot in pounds

PIPE SIZE O.D. 5s True 5 10s True 10 20 30 True 40 STD. 60 True 80 XH 100 120 140 True 160 XXH
1/8 0.405 .035
.1383
.049
.1863
.049
.1863
.068
.2447
.0668
.2447
.095
.3145
.095
.3145
1/4 0.540 .049
.2570
.065 .
3297
.065
.3297
.088
.4248
.088
.4248
.119
.5351
.119
.5351
3/8 0.675 .049
.3276
.065
.4235
.065
.4235
.091
.5676
.091
.5676
.126
.7388
.126
.7388
1/2 0.840 .065
.5383
.065
.5380
.083
.6710
.083
.6710
.109
.8510
.109
.8510
.147
1.088
.147
1.088
.187
1.304
.294
1.714
3/4 1.050 .065
.6838
.065
.6838
.083
.8572
.083
.8572
.113
1.131
.113
1.131
.154
1.474
.154
1.474
.218
1.937
.308
2.441
1 1.315 .065
.8678
.065
.8678
.109
1.404
.109
1.404
.133
1.679
.133
1.679
.179
2.172
.179
2.172
.250
3.765
.382
5.214
1 1/4 1.660 .065
1.107
.065
1.107
.109
1.806
.109
1.806
.140
2.273
.140
2.273
.191
2.997
.191
2.997
.250
3.765
.382
5.214
1 1/2 1.900 .065
1.274
.065
1.274
.109
2.085
.109
2.085
.145
2.718
.145
2.718
.200
3.631
.200
3.631
.281
4.859
.400
6.408
2 2.375 .065
1.604
.065
1.604
.109
2.638
.109
2.638
.154
3.653
.154
3.653
.218
5.022
.218
5.022
.343
7.444
.436
9.029
2 1/2 2.875 .083
2.475
.083
2.475
.120
3.531
.120
3.531
.203
5.793
.203
5.793
.276
7.661
.276
7.661
.375
10.01
.552
13.70
3 3.5 .083
3.029
.083
3.029
.120
4.332
.120
4.332
.216
7.576
.216
7.576
.300
10.25
.300
10.25
.438
14.32
.600
18.58
3 1/2 4.0 .083
3.472
.083
3.472
.120
4.973
.120
4.973
.226
9.109
.226
9.109
.318
12.51
.318
12.51
.636
22.85
4 4.5 .083
3.915
.083
3.915
.120
5.613
.120
5.613
.237
10.79
.237
10.79
.281
12.66
.337
14.98
.337
14.98
.438
19.00
.531
22.51
.674
27.54
4 1/2 5.0 .247
12.53
.355
17.61
.710
32.53
5 5.563 .109
6.349
.109
6.349
.134
7.770
.134
7.770
.258
14.62
.258
14.62
.375
20.78
.375
20.78
.500
27.04
.625
32.96
.750
38.55
6 6.625 .109
7.585
.109
7.585
.134
9.290
.134
9.289
.280
18.97
.280
18.97
.432
28.57
.432
28.57
.562
36.39
.719
45.30
.864
53.16
7 7.625 .301
23.57
.500
38.05
.875
63.08
8 8.625 .109
9.914
.109
9.914
.148
13.40
.148
13.40
.250
22.36
.277
24.70
.322
28.55
.322
28.55
.406
35.64
.500
43.39
.500
43.39
.594
50.87
.719
60.63
.812
67.76
.906
74.69
.875
72.42
9 9.625 .342
33.90
.500
48.72
10 10.75 .134
15.19
.134
15.19
.165
18.65
.165
18.70
.250
28.04
.307
34.24
.365
40.48
.365
40.48
.500
54.74
.594
64.33
.500
54.74
.719
76.93
.844
89.20
1.000
104.1
1.125
115.6
11 11.75 .375
45.55
.500
60.07
12 12.75 .156
21.07
.165
22.18
.180
24.16
.180
24.20
.250
33.38
.330
43.77
.406
53.53
.375
49.56
.562
73.16
.688
88.51
.500
65.42
.844
107.2
1.000
125.5
1.125
139.7
1.312
160.3
14 14.0 .156
23.07
.188
27.73
.250
36.71
.312
45.68
.375
54.57
.437
63.37
.375
54.57
.594
84.91
.750
106.1
.500
72.09
.938
130.7
1.094
150.7
1.250
170.2
1.406
189.1
16 16.0 .165
27.90
.188
31.75
.250
42.05
.312
52.36
.375
62.58
.500
82.77
.375
62.58
.656
107.5
.844
136.5
.500
82.77
1.031
164.8
1.219
192.3
1.438
223.5
1.593
245.1
18 18.0 .165
31.43
.188
35.76
.250
47.39
.312
59.03
.437
82.06
.562
104.8
.375
70.59
.750
138.2
.938
170.8
.500
93.45
1.156
208.0
1.375
244.1
1.562
274.2
1.781
308.5
20 20.0 .188
39.78
.218
46.05
.250
52.73
.375
78.60
.500
104.1
.594
122.9
.375
78.60
.812
166.4
1.031
208.9
.500
104.1
1.281
256.1
1.500
296.4
1.750
341.1
1.968
379.0
22 22.0 .250
58.07
.375
86.61
.500
114.81
.375
86.61
.875
197.42
1.125
250.82
.500
114.81
1.357
302.88
1.625
353.61
1.875
403.01
2.125
451.07
24 24.0 .218
55.37
.250
63.41
.250
63.41
.375
94.62
.562
140.8
.687
171.2
.375
94.62
.969
238.1
1.219
296.4
.500
125.5
1.531
367.4
1.812
429.4
2.062
483.1
2.343
541.9
26 26.0 .312
85.73
.375
102.63
.500
136.17
30 30.0 .250
79.43
.312
98.93
.312
99.08
.625
196.08
.375
118.65
.500
157.53
34 34.0 .312
112.43
.625
222.78
.688
244.60
.375
134.67
.500
178.89
36 36.0 .312
119.11
.625
236.13
.688
282.36
.375
142.68
.500
189.57
42 42.0 .625
276.17
.688
330.41
.375
166.71
.500
221.61
PIPE SIZE O.D. 5s True 5 10s True 10 20 30 True 40 STD. 60 True 80 XH 100 120 140 True 160 XXH

What is so essential regarding stainless-steel pipe weight chart?



The stainless pipe sizes schedules are there to give a combination of wall thicknesses and pipe outer diameters so that the coordination provides a degree of pressure capacity. The stainless steel pipe dimensions correspond to the pressure capacities. The pressure capacities are governed by the pressure classes such as 150, 300, 600, 2500 and by the PN6, up to PN64 pressure classes etc. The pressure classes help to determine which grade and dimensions of pipes are to be applied in specific applications. You can check our stainless steel pipe weight chart to know how heavy your applications would be or how heavy the pipes would weigh.

The calculation involves calculating the volume of stainless steel in a pipe. This can be done manually by taking the thickness of the pipe, the perimeter of the pipe diameter and then the length of the pipe and multiplying all these values by the density of the stainless steel material. Each grade of stainless steel has a different density. The weight chart makes it easy and provides you with accurate calculations. The ss erw pipe pressure rating depends on the wall thickness, diameter and the grade of stainless steel as well. Our ss seamless pipe weight chart will help you to understand the different weights caused by the different material and dimensions of pipes. This information is much useful for transportation of the stainless steel pipes. Please check the tables below for the charts.

ss pipe weight
ss pipe weight chart
SS Pipe Weight chart Metric
SS Pipe Weight chart Metric
SS Pipe Weight Per Meter
SS Pipe Weight Per Meter



How to calculate weight of schedule 40 stainless steel pipe per Meter?

There are two ways for calculating the weight of Schedule 40 stainless steel- either by comparing the parameters based on the weight chart or by using the weight formula. The formula is:

P= t(D-t)*C

Here, D is the external diameter specified according to the pipe chosen and is measured in inches. t represents the wall thickness of the tube and is expressed usually in mm or inches. C has a static value of 0.02466 as per the SI units and 10.69 according to USC units. The weight of the Schedule 40 stainless steel is expressed in kg/m and lb/ft based on the measurement class being used.

Difference between Schedule 10, SCH 20 and SCH 40 pipe

The schedule of pipes determines the extent of their wall thickness. Therefore, Schedule 10, 20, and 40 pipes can be differentiated based on how thick the pipe wall is. SCH 10 pipes are much thinner in comparison to SCH 20 and SCH 40 pipes. The exact wall thickness will vary from one pipe to another, even though the chosen products have SCH 40 or SCH 20 rating. Therefore, it is imperative for you to verify the actual thickness and then decide which schedule value will be suitable for you. Another factor that has an impact of the pipe schedule is the length like 1” pipe with SCH 40 will have different wall thickness as compared to a 2” SCH 40 pipe.

Stainless Steel pipe standard sizes and thickness

The stainless steel pipes are usually rated based on the ANSI or ASME 36.19M standards. The sizes of these pipes vary between 1/8 inches and 12 inches. As for the wall thickness, the values are divided as per the Schedule being chose. For example, SCH 10 pipes have thickness range from 1.25 mm to 4.58 mm. Similarly, if the SCH 40 pipes are considered, their wall thickness will vary between 1.73 mm to 9 53 mm. Hence, the application of the pipes is based on the SCH it has been rated for and hence, it’s important to consider size and thickness both as per the ASME chart.



What is ANSI B36.19?

ANSI B36.19is a standard used to define pipes made from stainless steel by using both welded and seamless method. Using this standard, several attributes of the pipes can be determined like the size measured in inches, the Schedule No, the length of the outside diameter. Another two most important factors that can be determined using the chart provided under this ANSI standard are the wall thickness and the internal diameter. Also, under this standard compliances and regulations, four wall thickness grades are determined namely the SCH 5, SCH 10, SCH 40, and SCH 80

What is Nominal Bore and outside Diameter in Stainless Steel Pipes and Tubes?

At the time of rating the pipes or determining the dependent attributes like tolerance level, pressure levels, and so on, the two most important factor that one needs to consider are the nominal bore and the outside diameter. The outside diameter or OD is represented in mm or inches and expresses the entire diameter measured in accordance with the external circumference of the cross sectional area. As for the nominal bore, it determines the inner diameter of the stainless steel pipes and tubes. It is also measured in mm or inches and depends of the thickness of the walls.

What is the meaning of stainless steel pipe gauge?

Stainless steel pipe gauge is used for determining the wall thickness. This particular attribute is represented in normal numbers like 5, 10, 20, 40, and more. Based on these numbers, the wall thickness of the pipes and tubes are measured. For example, a pipe with gauge number of 40 may have a wall thickness of 1.67 mm or 1.97 mm depending on the external and internal diameters. Higher the gauge number, less will be the wall thickness and more will be the bore or OD. Also, lower gauge pipes are stronger and more durable as compared to pipes with high gauge rating.

OD Tolerance for stainless steel pipe

The stainless steel pipes are usually rated based on the ANSI or ASME 36.19M standards. The sizes of these pipes vary between between 1/8 inches and 12 inches. As for the wall thickness, the values are divided as per the Schedule being chose. For example, SCH 10 pipes have thickness range from 1.25 mm to 4.58 mm. Similarly, if the SCH 40 pipes are considered, their wall thickness will vary between 1.73 mm to 9 53 mm. Hence, the application of the pipes is based on the SCH it has been rated for and hence, it’s important to consider size and thickness both as per the ASME chart.

Standard pipe size tolerance

The ASME standard 999 is considered for calculating the tolerance level of the pipes. According to this, the stainless steel pipes usually have an under tolerance of -0.031″ for all OD measurements. However, when the over tolerance is considered, the value will increase with the external diameter of the pipes.

Pipe thickness tolerance as per ASME

It is very difficult to determine what could be the actual thickness of the stainless steel pipes based on the bore and external diameter. Hence, it is important to consider both these parameters together and compare them with the standard ASME 999 chart for having the exact knowledge about the thickness. Furthermore, if we consider the seamless pipes, their actual thickness deviates from the set value by 12.5%.

ASTM standard for steel tube

For ensuring that all the steel tube manufacturers are on the same ground, eight compliance and regulatory standards have been introduced in the ASTM category. Based on these categorization, one can understand the physical and chemical attributes of the concerned steel tube with ease.

The eight main ASTM standards are as follows:
  •   ASTM A213 tubes have 1/8 inches thick walls with maximum inner diameter being 5 inches and OD being 0.5 inches.
  • ASTM A249 steel tubes are welded and usually used in boilers, heaters, conductors, and more.
  • ASTM A269 tubes can be subjected to different temperature classifications with ease since they have a wall thickness of ¼ inches
  • ASTM A270 is used to denote both seamless and welded steel tubes with a grade of TP 304, 316L, and the 316 grades.
  • ASTM A312 is used in food and dairy industry with tubes being made from both welding and seamless method.
  • ASTM A511 tubes are specifically made to tolerate high and extreme temperatures with ease. One can find both hot and cold finishing.
  • ASTM A554 determines the welded stainless steel tubes that are used for mechanical and structural purposes.
  • ASTM A778 tubes are made from welding the alloy without any annealing. They have an outside diameter of about 4 inches.

304 stainless steel pipe specifications

The stainless steel pipes with the 304 rating is one of the most used materials in different market. Commercially, it is known as the 18/8 stainless steel which means that the nickel percentage present in this alloy is approximately 80%. Following are the main specifications of the tubes having the ASTN 304 grade:

  • They have a tensile strength of approximately 515 MPa
  • The yield strength is roughly about 205 Mpa
  • It can be elongated by 35% minimum
  • The hardness of the 304 stainless steel pipes is about 90 HRB in the Rockwell category
  • For Brinell system, the hardness of these pipes is around 192 HB maximum.
  • The EN numbers for this grade of stainless steel is 1.4306 and 1.4301
  • DIN standards are rated for X 2 CrNi 19 11*, and X 5 CrNi 18 10*
  • Density of the 304 stainless steel is 7.93 kg/dm3
  •  The thermal conductivity of this stainless steel grade is approximately around 16.2 W/m K measured at 100-degrees while for 500-degrees, the conductivity increases to 21.5 W/m.K.
  •  It also has electrical resistivity around 720 nW.m

Due to all these amazing specifications, the stainless steel is used for several applications, starting from heat exchangers, petrochemical equipment pieces, nuclear power machinery, and so on.

What is the difference in sizes of stainless steel seamless and welded pipes?

In the seamless tubes, a single material sheet is rolled up to form the long cylinder while in the welded tubes, you will find that their lengths are joined together and hence, there will be a lot of seams throughout the total length of the pipes. Due to the differences in construction processes and physical and chemical attributes, the seamless and welded stainless steel pipes have different sizes. For example, the seamless pipes will come with the external diameter of 20 inches while that of the welded one will be approximately about 16 inches.

Major difference in dimensions of ASTM A312 stainless Steel Pipes and ASME SA312 Tube Dimensions

If stainless steel pipes having the 312 gauge rating is considered, there are two different ASTM standards- the A312 and SA312. Due to the differences in the standards, the dimensions of stainless pipes will also differ. The tensile strength of the A312 pipes is about 485 MPa and yield strength is about 170 MPa minimum. As for the elongation, it is rated at 35% minimum. It will further vary in accordance with the welded and seamless tubes because of the differences in the manufacturing, the presence of seams, and wall thickness

Din standard for stainless steel pipes

For making sure that the dimensions of the stainless steel pipes are intact and universal, irrespective of the manufacturer, ISO has introduced the DIN EN ISO 1127 standard. This particular standard consists of all dimension specifications mentioned in the DIN 2462 describing seamless pipes and DIN 2463 determining the welded stainless steel tubes. Under this DIN 1127, the three main factors which are defined properly are the total length of the tubes, other sizing dimensions, and also the limit allowances.

When the outer diameter is concerned, there are four D-group classifications like:

  • D1 with a tolerance of +/- 1.5% and a minimum diameter of +/- 0.75mm
  • D1 with a tolerance of +/- 1% and a minimum diameter of +/- 0.5mm
  • D1 with a tolerance of +/- 0.75% and a minimum diameter of +/- 0.3mm
  • D1 with a tolerance of +/- 0.5% and a minimum diameter of +/- 0.1mm

As far as the wall thickness is considered, there are five standard values which are as follows:

  • T1 with +/- 15% tolerance and a minimum value of +/- 0.6mm
  • T1 with +/- 12.5% tolerance and a minimum value of +/- 0.4mm
  • T1 with +/- 10% tolerance and a minimum value of +/- 0.2mm
  •  T1 with +/- 7.5% tolerance and a minimum value of +/- 0.15mm
  • T1 with +/- 5% tolerance and a minimum value of +/- 0.1mm
